Features
- Concentric Vent or 2 in. Exhaust: Allows for easy use of concentric 2/4 in. or 3/5 in. direct vent or exhaust in 2 in. pipe or room-air configurations
- 2 in. Intake Vent Connections: Allows for maximum flexibility with the use of 2 in. PVC/CPVC/PP on vent runs up to 65 ft.
- Primary Stainless Steel Heat Exchanger: Resists the corrosive nature of the condensate, which occurs early in the highefficiency combustion process
- Fiber Mesh Premix Burner: Provides even flame distribution for optimal performance for any demand
- Integrated Check Valve: Located between the turbo fan and combustion chamber. Prevents cold air from entering the venting system and backflow of exhaust in common vent applications
- Turbo Fan: Enables longer vent runs and flexible vent options. Up to 65 feet vent runs with 2/4 in. concentric and 2 in. PVC/CPVC/PP. Up to 150 ft. vent runs with 3/5 in. concentric and 3 in. PVC/CPVC/PP
- Switching Venturi: Provides consistent mixture of air and gas to burner for low turndown ratios. Self-compensates in areas with low or fluctuating gas pressures
- NEW Zero Governor Gas Valve: Optimizes combustion performance by consistently delivering gas and air mixture
Specifications
-
AMP4
-
CoatingTitanium
-
End ConnectionNPT
-
End Connection 1NPT
-
End Connection 2NPT
-
Energy Star CompliantYes
-
Fuel TypeNatural Gas
-
Height31-3/10 in.
-
Ignition SystemDirect Electronic Ignition
-
Installation TypeWall Mount
-
Lead Law CompliantYes
-
MaterialStainless Steel;Plastic
-
Material TypeCPVC;40LPVC;Polypropylene
-
Maximum Temperature140
-
MBH160 MBH
-
PhaseSingle Phase
-
Power SourceGas
-
Pressure - Maximum150 psi
-
Style NameSENSEI SE+ Series
-
Supply Pipe Connection Size3/4 in.
-
Temperature Range98 to 185 Deg F
-
Vent TypeConcentric
-
Volts120V
-
Water Heater TypeTankless
-
Watts52 W
-
Weight61.72 lb
-
ApplicationResidential
-
Product TypeWater Heater
-
Specifications - CEC CompliantFor Sale in CA
